Technical parameter
Receiver Technical Parameters
Carrier frequency band: UHF 500~950MHz (standard: 640-690 MHz)
Number of channels: 200
Modulation method: Broadband FM
Band width: 50MHz
RF stability: ± 0.005% (-10~50 ℃)
Reception method: Dual tuner automatic selection
Mirror suppression: ≥ 80dB
Sensitivity: When the offset is equal to 40KHz and 6dBuV is input, S/N>80dB
Integrated distortion T.H.D.:<0.5% @ 1KHz
Comprehensive S/N ratio:>105dB (A)
Maximum offset: ± 68KHz with volume expansion
Comprehensive frequency response: 70Hz~18KHz ± 3dB
Maximum output voltage: Balanced:+10dB (2.5V)/600 Ω, Unbalanced:+4dB (1.25V)/5K Ω
Mute control mode: Dual mute control for 'audio code and RF intensity'
DC power supply: 12V/850mA
Maximum receiving distance: 100 meters
