Technical Parameters
Frequency range: 640-690MHz
Adjustable channel count: 100x2
Oscillation mode: phase-locked loop frequency synthesis (PLL)
Frequency stability: ± 10ppm
Receiving method: Super heterodyne secondary frequency conversion
Receiving sensitivity:- 95~-67dBm
Audio frequency response: 40-18000Hz
Harmonic distortion: ≤ 0.5%
Signal to noise ratio: ≥ 110dB
Audio output: balanced output and mixed output
Transmission power: 3-30mW
Modulation method: Frequency Modulation (FM)
Battery specification: 2 No. 5 batteries
Power specifications: 100-240V 50-60Hz 12VDC (switch power adapter) or 220VAC/50-60Hz 12VDC (linear power supply)
Power consumption: ≤ 10W
