G-210

G-210 adopts a passive three-way coaxial line array speaker with high performance, high power and small size. It contains 2x10-inch low-frequency driver units. One 8-inch

 mid-frequency driver unit with a horn, and one 1.4-inch throat (75mm) coaxial high-frequency compression driver unit. The high-frequency compression driver unit is

equipped with a dedicated waveguide device horn. The low-frequency driver units are arranged in a dipole symmetric distribution around the center of the enclosure.

The mid and high-frequency components in a coaxial structure are installed at the center of the enclosure, which can ensure the smooth overlap of adjacent frequency

bands in the design of the frequency division network. This design can form a 90° constant directivity coverage with excellent control effect, and the control lower limit

extends to 250Hz. The enclosure is made of imported Russian birch plywood and coated with polyurea coating that is resistant to impact and wear. The front of the speaker

 is protected by a rigid metal grille.

Product Model: G-210

Type: Dual 10-inch coaxial three-way line array speaker

Configuration: LF: 2x10'' low-frequency units, MF: 1x8'' paper cone mid-frequency unit, HF: 1x3'' (75mm) compression coaxial unit

Rated Power: LF: 600W, MHF: 380W

Frequency Response: 65Hz - 18KHz

Sensitivity: 103dB

Maximum Sound Pressure Level: 134dB / 140dB (AES / PEAK)

Rated Impedance: 16Ω

Coverage Range (HxV): 90° x 14°

Input Interface: 2 Neutrik 4-core sockets

Dimensions (W * H * D): 760 * 310 * 470mm

Weight: 37.8 kg
